In stock and ready to ship
Monoforged 2.0 is here - Die Forged manufacturing brings affordability.
Elite Forged Strength. Unbeatable Price.
True Forged Performance, Now for Everyone. We set the standard for affordable, high-quality monoblock forged wheels. Now, with Monoforged 2.0, we’re raising the bar again-delivering the most advanced, efficient, and accessible forged wheels ever made.
The Technology: Forged for the Future
Closed Die Forging: The OEM Secret, Now in Your Wheels
How It Works:
Unlike cast wheels, which pour molten aluminum into a mold, Monoforged 2.0 wheels begin as a solid billet of aerospace-grade 6061-T6 aluminum. Through a combination of intense pressure and controlled heat, we reshape the grain structure — not just the form — of the metal.
-
Start with a billet of aerospace-grade 6061 aluminum
-
Shape the wheel under thousands of tons of pressure in a closed die
-
Flow-form the barrel for optimal strength and weight
-
Minimal CNC finishing-less waste, more efficiency
Result:
A true forged wheel at a price that rivals cast.
A fine-grain, multi-directional structure that maximizes strength where it matters most — across the entire wheel, especially in high-stress zones.

What Makes Forging Superior:
-
No Porosity: Because the aluminum is never liquified, we eliminate voids and weak points common in casting.
-
Directional Grain Flow: Spin-forging the barrel creates a radial grain alignment, increasing impact resistance and load capacity.
-
One-Piece Integrity: With no welds, seams, or joints, structural reliability is dramatically improved — just like aerospace components.
-
Optimized Weight-to-Strength Ratio: Material is precisely removed where it’s not needed and reinforced where it is.
6061 Forged vs. A356 Cast: The Real Difference
-
6061-T6 Forged Aluminum
-
No porosity, consistent strength
-
Superior elongation, fatigue, tension, and yield strength
-
Handles stress and impact without cracking
-
A356 Cast Aluminum
-
Prone to porosity and oxide inclusions
-
Lower strength, less fatigue resistance
-
Higher risk of cracking under stress
Specs & Features
Load Rating: 2,500+ lbs
Lighter. Stronger. Smarter. And Still Affordable.
Monoforged 2.0 isn’t just a performance upgrade — it’s a smarter buy.
So we engineered a forged wheel that:
Saves rotational mass
Boosts strength
And does it at a price that competes with cast wheels
No middlemen. No inflated branding. No waitlist.
Just elite-level forged wheels, finally within reach.
Here’s the weight breakdown (17x8.5 +0 example):
|
Wheel Type
|
Weight
|
|
Standard Gravity Cast
|
28 lbs
|
|
Cast Flow Form
|
23 lbs
|
|
Monoforged 1.0 (Machined from a billet blank)
|
23 lbs
|
|
Monoforged 2.0 (Die Forged)
|
22 lbs
|
Specifications
Size: 17x8.5
Bolt Pattern: 6x135 +0 and 6x5.5 / 6x139.7 -25
Center Bore for 6x135: 87.1mm (hub-centric for F150 / Raptor)
Center Bore for 6x139.7: 106.1mm (hub-centric for 3G Tacoma, 4Runner, GX470)
Load Rating: 2500 lbs
Backspacing: varies
Compatible with TPMS and Extended Thread (ET) Lugs
Customization Options (Accessories)
- Add accessory bolts only in black or gold finishes
- Add Protection Rings
- Protection Rings can be replaced once worn if heavily damaged
- Add a Forged Beadlock Ring made of aluminum that includes longer grade 10.9 bolts by clicking here
- The beadlock ring is intended for offroad use ONLY
Vehicle Fitment
6x135: Ford F150 / Raptor
6x139.7: Toyota Tacoma (2023 and older), 4Runner, FJ, Lexus GX470, Chevy Silverado
Manufactured in a JWL/VIA Certified Facility and tested to meet and exceed OEM specifications
RR7-H with the true beadlock ring is for offroad use ONLY and NOT street use. *Renders are for reference only.
